XH-001
Colourful Tiger
老虎灯光控制台

体积小巧，重量轻盈，方便携带，功能强大，是中大型文艺演出、流动
演出、娱乐场地演出的首选内置闪存驱动器，比硬盘更快更可靠、容量
充足，可以存储：
3000个以上灯库文件过百内置图形可移动扩展记忆棒3000个以上内置
灯库改进了的灯具选择和配置方法
新的灯具查找按键 省略了上排推杆，缩短了程序滚筒，简化了版面
4096个DMX512通道
可配置256台电脑灯不同地址码时可配置256台常规灯具不同地址码时
10个回放推杆，并包含剧场操控方式 120个内置图形
可保存300个演出程序或场景 可用MIDI信号或低音、中音、高音声控
触发演出程序
可外接彩色VGA显示屏 采用钻石4控台的面板技术面板使用PVC面
贴，美观而且耐磨
毛重：30kg
净重：12kg
包装尺寸：730×530×310mm
产品尺寸：640×440×140mm

Small size, light weight, easy to carry, powerful, medium and large-scale
theatrical performance, flow
The preferred built-in flash drive for performances, entertainment venues,
faster and more reliable than hard drives, capacity
Adequate, can store:
More than 3000 built-in graphics, more than 3,000 built-in graphics, and
more than 3,000 built-in removable memory sticks
Lamp bank improved lamp selection and configuration method
New luminaire search button Eliminate the upper row fader, shorten the
program cylinder, simplify the layout
4096 DMX512 channels
Configurable 256 sets of scanners with different address codes can be
configured with 256 conventional lamps with different address codes
10 Playback Faders and Theater Play Modes 120 Built-in Graphics
300 performance programs or scenes can be saved with MIDI signals or
bass, midrange, and high-pitched voice controls
Triggering the show program
Can be connected to a color VGA display Panel using Diamond 4 console
technology panel using PVC surface
Stickers, beautiful and wearable
Gross weight: 30kg
Net weight: 12kg
Packing size: 730×530×310mm
Product size: 640×440×140mm
